When problems occur with the Internet or private IP networks, Traceroute can give you insight into how your data packets travel from your PC to the destination device. This information is gathered through network mechanisms called TTL (Time to Live) and RTT (round-trip time).
If you notice elevated latency near the beginning of your traceroute results, this likely indicates a local issue that can be resolved by working with your network administrator.
Identifying Network Issues
The results of a traceroute can tell you where in the network data packets are taking longer than usual to reach their destination. This can help you pinpoint the source of your network issues and work with your ISP or website/service provider to resolve them.
Traceroute sends data packets to servers along the path to your destination. Each server, called hops, records the round-trip time for these packets. A typical network should have consistent hop-to-hop latency. If this doesn’t happen, it may indicate a problem with your network configuration or ISP.
To begin a traceroute of an IP, you need to know the IP address of your target website or service. Then, run the following command from your computer:
When interpreting traceroute results, look for consistent times (RTT) throughout each hop. High latency at the beginning of the report could indicate an issue with your local network or a server/router slowing things down. Alternatively, suppose latency is elevated at one point and decreases toward the end of the report. In that case, it may indicate that the problem is somewhere between you and your ISP. You can also use other network diagnostic tools to test your connections and identify potential bottlenecks in your network. You can then take steps to correct these issues and improve performance.
Identifying Router Issues
When troubleshooting connectivity issues, traceroutes can help pinpoint the source of problems. Determining where the problem occurs along the path of data packets makes it possible to determine whether the issue is with your local network, your ISP, or a website or service you’re trying to reach.
Traceroute sends a sequence of ICMP echo packets to the routers that make up the route to the destination. Each box has a Time to Live (TTL) value that decreases by one each time it passes through a router. When the TTL reaches zero, the router will send back a “TTL exceeded” message to the source. The traceroute command then sends another packet with a lower TTL, and so on, until the destination host is reached or the maximum number of hops – usually 20 – is reached.
The resulting output from the traceroute command shows each router in the path to the destination, along with the round-trip time (RTT) measured for each packet in milliseconds. A typical output will contain several columns, the first of which includes the hop number, the second identifies the name or IP address of the router, and the third column lists the average RTT in milliseconds across all three test attempts.
In addition to the traditional ICMP-based traceroute, some variants utilize different protocols, such as User Datagram Protocol (UDP) and Transmission Control Protocol (TCP). These methods avoid relying on ICMP, which firewalls or other network devices can block. They also mimic the behavior of applications that use these protocols, which offers a more complete picture of the network path.
Identifying Firewall Issues
Many MSPs and IT admins know about the network diagnostic tool called traceroute. It maps the route data takes to reach a destination, such as a website or an internal server. This allows you to identify the path the data travels, potential bottlenecks, and other issues like latency and packet loss.
The process is simple enough: Traceroute sends a series of data packets to a destination and records the time it takes for each hop or device (such as a router or switch) along the way. This is known as the round-trip time or RTT. Each ball is identified by its IP address and, in some cases, a name. The list of devices and their corresponding RTTs is then displayed in an output.
To collect these RTTs, traceroute uses Time to Live (TTL). Each packet sent out has a TTL value that determines how long it can remain in the network before being discarded. When the TTL value of a box reaches zero, the router will discard it and send back an ICMP “Time Exceeded” message to the source. Traceroute uses these responses to build a list of intermediate hops and their IP addresses.
Some tools allow you to specify different port numbers or protocol types for the ICMP echo request packets to bypass any firewall restrictions that may hinder a Traceroute’s ability to gather information. This allows them to probe hops that might not respond to ICMP queries if they are blocked by the firewall, giving more accurate results and better insights into network paths.
Identifying Network Bottlenecks
When users report slow performance on a network, it can be difficult to pinpoint where the issue is occurring. Traceroute, a network troubleshooting tool that uses the ICMP protocol (the same as ping), can help you identify problem areas on your network. Essentially, traceroute sends packets to different routers along the route to your network destination. Each box has a specific time-to-live value or TTL. As the packets travel through the network, each router will ignore the next until the TTL reaches 0, and the final router will send back an error message. Traceroute can map the path the data packets traveled to reach your network destination by analyzing the resulting error messages.
Aside from displaying the number of hops between your system and the target host, a traceroute report can also offer insights into the network bottlenecks that may be slowing down your network. The shortest RTTs are typically the most vital information to focus on when interpreting a traceroute report. Anomalous high RTTs or significant delay variations can signal network congestion, making the data transmission process more inefficient.
In addition to displaying hop numbers, traceroute results often show IP addresses and domain names (if resolved) for each router or intermediate device encountered on the network route. This information can help identify the routers or systems responsible for the slow response times.
